Suzuki SWIFT 2005 User Manual

9A-21 Wiring Systems:
J: Front door wire (Drive side)
J: Front door wire (Passenger side)
J: Rear door wire
K: Roof wire
No./Color Connective position No./Color Connective position
J01/N Floor harness (To L07) J06/N Front door lock switch (Driver side)
J02/BLK Tweeter (R) J07/N Power mirror switch (Driver side)
J03/N Power mirror motor (R) J08/BLU Power window main switch
J04/N Front speaker (R)
J26/N (IF
EQPD)
Door antenna (Driver side)
J05/GRY Front power window motor (Driver side)
J27/N (IF
EQPD)
Request switch (Driver side)
No./Color Connective position No./Color Connective position
J09/N Floor harness (To L03) J14/GRY Front power window motor (Passenger side)
J10/BLK Tweeter (L) J15/N Power window sub switch
J11/N Power mirror motor (L)
J28/N (IF
EQPD)
Door antenna (Passenger side)
J12/N Front speaker (L)
J29/N (IF
EQPD)
Request switch (Passenger side)
J13/N Front door lock motor (Passenger side)
No./Color Connective position No./Color Connective position
J16/N Floor harness (To L13) J21/N Floor harness (To L37)
J17/N Rear speaker (R) J22/N Rear speaker (L)
J18/BLK Rear power window motor (R) J23/BLK Rear power window motor (L)
J19/N Rear power window sub switch (R) J24/N Rear power window sub switch (L)
J20/N Rear door lock motor (R) J25/N Rear door lock motor (L)
No./Color Connective position No./Color Connective position
K01/N J/B K02/N Interior light
