1A-208 Engine General Information and Diagnosis:
11 A/C compressor relay circuit check
1) Measure voltage between “E23-47” wire terminal of
ECM connector and vehicle body ground under following
conditions respectively.
Voltage between “E23-47” terminal of ECM
connector and ground
While engine running and A/C switch turned OFF: 10
– 14 V
While engine running, A/C and blower speed
selector switch turned ON: 0 – 1 V
Is check result satisfactory?
Go to Step 12. Go to Step 13.
12 A/C compressor relay check
1) Check A/C compressor relay referring to “Compressor
Relay Inspection in Section 7B” or “Compressor Relay
Inspection in Section 7B”.
Is it in good condition?
A/C compressor drive
circuit malfunction.
Replace A/C
compressor relay.
13 A/C compressor relay circuit check
1) Remove A/C compressor relay with ignition switch
turned OFF.
2) Turn ON ignition switch, measure voltage between “BLK/
RED” wire terminal of A/C compressor relay connector
and vehicle body ground.
Is voltage 10 –14 V?
Go to Step 14. “BLK/RED” wire is open
circuit.
14 A/C compressor relay check
1) Check A/C compressor relay referring to “Compressor
Relay Inspection in Section 7B” or “Compressor Relay
Inspection in Section 7B”.
Is it in good condition?
“GRY” wire is open
circuit. If OK, substitute
a known-good ECM and
recheck.
Replace A/C
compressor relay.
Step Action Yes No
