SVAN 948 USER MANUAL

3 - 17

Table of Contents

Default Chapter3
- Table of Contents3
1 Introduction14
2 Manual Control of the Instrument14
- Control Push-Buttons on the Front Panel14
- Input and Output Sockets of the Instrument17
3 Setting of the Instrument20
4 Measurement Functions of the Instrument44
- Calibration46
  - The Calibration by the Sensitivity Introduction47
    - Calibration by SENSITIVITY in the Case of Vibration Signal47
    - Calibration by SENSITIVITY in the Case of Acoustic Signal48
  - The Calibration by the Measurement50
    - Calibration by MEASUREMENT in the Case of Vibration Signal50
    - Calibration by MEASUREMENT in the Case of Acoustic Signal51
- Level Meter53
Activation of Optional Functions81
1/1 Octave Analyser82
- 1/1 OCTAVE Analyser of Acoustic Signal83
  - Selection of the Measurement Range in 1/1 OCTAVE Analysis of Acoustic Signal - RANGE86
    - Buffers Setup87
  - Selection of 1/1 OCTAVE Analysis Parameters for Acoustic Signal - SPECTRUM89
- 1/1 OCTAVE Analyser of Vibration Signal92
  - Measurement Range Selection in 1/1 OCTAVE Analysis of Vibration Signal - RANGE96
    - Buffers Setup97
  - Selection of 1/1 OCTAVE Analysis Parameters for Vibration Signal - SPECTRUM98
    - Buffer99
    - Selection of the Result Which Triggers Registration in BUFFER Mode in 1/1 OCTAVE Analysis of Vibration Signal100
1/3 Octave Analyser101
5 Auxiliary Functions133
Saving the Measurement Results168
- Saving Files168
- Operations in Buffer188
