TimeHub 5500 TL1 Reference Manual
Commands
097-55501-02 Issue 5: June 2003
SSSSSSSSSSS SSSS S SSSSS SSSSSSS S SSS S SSSSS S
2
Edit Equipment
This command is used to change equipment parameters. To change parameters for
a specific input or output port, refer to the Edit Sync command. The command
format is:
ED-EQPT[-TSG]:[<tid>]:<aid>:<ctag>:::<keyword>=<value>;
Parameter Value Variables Description
<aid> CLK — Clock card
IMC Management card
Sa-OUTb a = 0 – 4 Shelf number. Zero (0) is master or remote,
1 – 4 are expansion shelves. S0-OUTb
can always be shortened to OUTb.
b = A, B, C, or D Output driver card letter
Sa-CLKb
a = 1 – 4 Expansion shelf
b = 1, 2 Expansion controller card
1 = EC1 (leftmost slot)
2 = EC2 (rightmost slot)
Sa-OUTb-PGc
a = 0 – 4 Shelf ID. 0 = master or remote shelf. S0- is
optional. 1 – 4 are expansion shelves.
b = A, B, C, ..., H Output group. For master or remote shelf,
range is A – D. For expansion shelf, range
is A – H.
c = 1, 2 Port group. PG1 identifies ports 1 – 20.
PG2 identifies ports 21 – 40.
