98
TimeHub 5500 TL1 Reference Manual
Commands
097-55501-02 Issue 5: June 2003
SSSSSSSSSSS SSSS S SSSSS SSSSSSS S SSS S SSSSS S
2
Set Threshold
This command changes the threshold of a measurement for a particular input
channel, and specifies a measurement threshold that automatically disqualifies an
input signal when the threshold is exceeded, provided the CRI property of the
measurement is set to Y.
Thresholds can also be used to cause automatic reporting of the measurement
when it crosses the threshold in either direction (using the RPT property of the
measurement). (See the Performance Monitoring chapter.) The command format is:
SET-TH[-TSG]::<aid>:<ctag>::<montype>,<value>;
Command Example:
SET-TH::CLK-2:SC1::LMRTIE-15M,100;
This example sets a threshold of 100 ns on the LMRTIE-15M measurement for
clock input channel 2.
Parameter Value Variables Description
<aid> CLK-a a = 1 to 4 Input port number of clock card
<montype> See the Performance Monitoring chapter
<value> a If <montype> = TDEV:
a = 0 to 800,000
Threshold value for TDEV in
nanoseconds. Factory setting is 0.
a If <montype> = MRTIE:
a = 0 to
1,900,000,000
Threshold value for MRTIE in
nanoseconds. Factory setting is 0.
a If <montype> = LMRTIE:
a = 0 to
1,900,000,000
Threshold value for LMRTIE in
nanoseconds. Factory setting is 0.
a If <montype> = SPRD:
a = 0 to 7,300,000
Threshold value for SPRD in parts per
million. Factory setting is 0. No input
port is specified in <aid>.
a If <montype> = FFOFF:
0 to 7,300,000
Threshold value for FFOFF in parts per
million. Factory setting is 0.
