6. The commands can now be entered, writing the string in the provided area.
Select the available COM
Command input eld
Make sure +CR is agged
Select the Baud Rate 19200
Select DTR
Figure 86
9.2 STRUCTURE FOR ENTERING COMMANDS
The structure of the command/message is: @COMANDO [ARG1] [ARG2]#
Character Required Description
@ YES Message start marker.
COMMAND YES
Command. The acceptable commands are described in the
following sections.
ARG1 NO First Topic of the command (if required by the command).
ARG2 NO Second Topic of the command (if required by the command).
#
(hash)
YES Message end marker.
Table 22
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 104
