11.4.3 REPLACING THE
RIGHT AND LEFT
PEDAL CRANK
1
1
Figure 148
Remove the pedal crank as indicated in “11.4.1
Removing the right pedal crank” or “11.4.2 Re-
moving the left pedal crank”.
1. Use the previously-removed screw (1)
and tighten with a torque wrench set be-
tween 47Nm (34.7 lbf-ft) and 54Nm (39.8
lbf-ft).
2. Remove the screw (1).
3. Tighten the (new) screw (1) with a torque
wrench set between 47Nm (34.7 lbf-ft)
and 54Nm (39.8 lbf-ft).
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 156
