Technogym Group Cycle D92 - Removing the Console with Velcro

If instead the perforated handlebar is found
intheeld,theconsolewithvelcromustbe
fastened to it: remove the rear cover from the
consolewithprojectionsandfastenittothe
new console. The console is fastened to the
handlebar with screws.
11.1.1 REMOVING THE
CONSOLE WITH
VELCRO
1
Figure 106
1. Remove the lock pin (1) to release the clip
securing the cable to the handlebar post.
