Technogym Group Cycle D92 - Removing the Console with Projections

11.1.2 REMOVING THE
CONSOLE WITH
PROJECTIONS
1. Carry out the removals described in the par-
agraph “11.1.1 removing the console with vel-
cro”, from point 1 to point 3.
2. Remove the 4 screws and spacers that fasten
the console to the handlebar.
Figure 114
3. Remove the console.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 137
