Figure 113
7. Exert pressure from both sides until the
console locks into place.
8. Reconnect the connector: insert the cable
back in the handlebar post until reposi-
tioning the clip securing the cable in its
seat, then reposition the lock pin.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 136
