Technogym Group Cycle D92 - Pedal Crank

12.2 PEDAL CRANK
1
1
Figure 254
1. Tighten the screw (1) with a torque wrench set between 47Nm and 54Nm.
WARNING: The pedal cranks must be tightened individually, one at a time. Counteract the
force applied to the torque wrench using the pedal crank.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 208
