Technogym Group Cycle D92 - Fitting the Handlebarsvertical Slider Back Onto the Bike

11.6.5 FITTING THE
HANDLEBAR’S
VERTICAL SLIDER
BACK ONTO THE BIKE
2
Figure 201
1. Insert the post (2) into its housing.
7
2
Figure 202
Connect Version.
2. Insert the cable (7) into the post, then in-
sert the post (2) into its housing.
WARNING: Be careful with the cable
(7).
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 183
