Technogym Group Cycle D92 - Removing the Generator

5
Figure 248
11.9 REMOVING THE
GENERATOR
1
2
Figure 249
3. Remove the electronics box (5).
To t the electronics back on the bike, follow the
aforementioned instructions in the reverse order.
Remove electronics as indicated in “11.8 Disas-
sembling the old electronics (rev. 1)”.
1. Remove the belt (1) from the generator (2).
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 203
