Technogym Group Cycle D92 - Soft Calibration of the Brake

6
7
Figure 39
6. If the template does not enter or
if the brake is too high (the two
upper magnets do not touch the
template) the acorn nut (6) must
be adjusted until reaching the
correct position of the brake with
respect to the template.
7. Then, lock the acorn nut with the
locknut (7).
If the acorn nut is worn, replace it
with a new one.
6.5.4 SOFT CALIBRATION OF THE BRAKE
 Whencalibratingthebrake,theWaSensorboard MUST NEVER BE TURNED OFF, as the data
will NOT BE SAVED. Carry out brake calibration when powering the display with a PC or a power
banktokeepitfromturningo.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 64
