2.7.3 CABLE TABLE
The colour of the cables may change: in particular, refer to the Pin Out.
2.7.3.1 CABLES USED IN THE OLD AND NEW ELECTRONICS
0WCU0810xx: Power supply cable for Console - high
CPU Board Signal Colour
Handlebar connec-
tor
1 5.5 V Red 1
2 Tx Out (to Console) Brown 2
3 GND Black 3
4 N/A Green 4
5 RPM Yellow 5
6 Rx In (from Console) Orange 6
Table 9
0WCU0811xx: Power supply cable for Console - low
Voltage converter Signal Colour
Handlebar connec-
tor
1 5.5 V Red 1
2 Tx Out (to Console) Brown 2
3 Rx In (from Console) Orange 6
4 RPM Yellow 5
5 GND Black 3
6 N/A Green 4
Table 10
2.7.3.2 CABLES USED IN THE NEW ELECTRONICS
0WCU0957xx: Generator cable
Generator Signal Colour Voltage converter
1 AC3 ( DC - ) Green 1
2 AC1 ( RPM ) White 3
3 AC2 (DC+) Brown 2
Table 11
