 Signal Colour Voltage converter
1 VDC Red 1
2 GND Black 2
3 Tx Out (to Console) Brown 4
4 Rx In (from Console) Orange 5
5 RPM Yellow 3
6 - N/A -
Table 12

 Signal Colour Hall Sensor
1 AD Brown 3
2 GND Black 2
3 VDC Red 1
Table 13
