Technogym Group Cycle D92 - Disassembling the Old Electronics (Rev. 1)

11.8 DISASSEMBLING THE OLD ELECTRONICS (REV.
1)
1
2 3
Figure 246
Remove the main left guard as indicated in
“11.3.3 Removing the main left guard”.
1. Disconnect connectors (1), (2) and (3).
4
Figure 247
2. Remove the screws (4) using a Phillips
screwdriver.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 202
