Technogym Group Cycle D92 - Removing Sleeve Bushings and Regulation the Post

11.7.4 REMOVING SLEEVE
BUSHINGS AND
REGULATION THE POST
1
Figure 232
Remove the seat’s vertical slider as indicated in
“11.7.3 Disassembling the seat’s vertical slider”,
from point 1 to point 6.
WARNING: make sure no objects fall
into the frame.
1. Remove the register (1) from its seat.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 196
