4
Figure 130
4. Loosen the screws (4) with a 3 mm Allen
wrench.
5
Figure 131
5. Remove the screw (5) with a 3 mm Allen
wrench.
6
Figure 132
6. Rotate the pedal crank in the upright po-
sition (6).
