Technogym Group Cycle D92 - Page 194

8
Figure 228
9. Work from both sides to loosen the lever
(8) and remove the lever (8) from the seat
post.
9
10
Figure 229
10. Remove the bush (9) and the pin (10).
11
11
Figure 230
11. Remove the screws (11) with a 3 mm Al-
len wrench.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 194
