A
Figure 43
3. Remove the screws that fasten the cover to the box. Remove the cover (B).
B
Figure 44
4. Remove the screws that fasten the Wa Sensor ID board to the box.
5. Disconnect the two cables connected to the Wa Sensor ID board.
6. Replace the Wa Sensor ID board with the new Wa Sensor ID board. ATTENTION: the passage
of the pre-existing cables must be guaranteed. The two cables that exit the cover must cross, as
New Group Cycle (D92):
