156
:TSSE:FORM LIN ----Set the LCR sweep coordinate as linear coordinates
:TSSE:FORM LOGX ----Set the LCR sweep coordinate as the X axis logarithm
:TSSE:FORM? ----Query the LCR sweep coordinate mode
9.2.14.6 Max-Min
 Description: Set the LCR curve Max-Min switch
Command systax:
:TSSE:LIMIt?
:TSSE:LIMIt <OFF|0|ON|1>
Parameter:
Example:
:TSSE:LIMI 0 ----Set the LCR sweep limit switch to OFF
:TSSE:LIMI OFF ----Set the LCR sweep limit switch to OFF
:TSSE:LIMI 1 ----Set the LCR sweep limit switch to ON
:TSSE:LIMI ON ----Set the LCR sweep limit switch to ON
:TSSE:LIMI? ----Query the LCR sweep limit switch status
9.2.14.7 Function Parameters
 Description: Set the LCR sweep "function" parameters
Command systax:
:TSSE:IMP[1|2|3|4]?
:TSSE:IMP <para1,para2,para3,para4>
:TSSE:IMP<1|2|3|4> <para>
Parameter:
para1,para2,para3,para4 ----indicates the optional function parameter name, the value is as follows:
Parameter
name
Parameter
meaning
Parameter
name
Parameter
meaning
CP
Equivalent parallel
capacitance
CS
Equivalent series
capacitance
LP
Equivalent parallel
inductance
LS
Equivalent series
inductance
RP
Equivalent parallel
resistance
RS
Equivalent series
resistance
GP
Conductance
BP
Susceptance
Z
Absolute value of
impedance
Y
Absolute value of
admittance
D
Loss factor
Q
Quality factor
ZTD/DZ
θz° Impedance degree
ZTR/RZ
θz Impedance radian
YTD/DY
θy°Admittance degree
YTR/RY
θy Admittance radian
X
Reactance
RD
DC Resistance
