2 Using the Control Box and Lightbars
2.7 Operating the remote switches
The remote switches let you use commonly used features while keeping your hands
close to the machine controls. The remote switches let you perform the following
operations:
2.7.1 3D remote switch
The 3D excavator system supports the use of a remote switch for:
l turning map recording events on and off:
Pass count coverage – On/Off/Auto.
Radio Map – On/Off/Auto.
Terrain – On/Off/Auto.
Cut/Fill Map – On/Off/Auto.
l recording a point.
Configuration of which of these events (if any) is available is managed by your Site
Supervisor.
Note – 3D remote switch support is not available when using a 2D Depth and Slope
system.
2.8 System beeper
In addition to the display and lightbars the system also uses an audible alarm, or
beeper, to alert you to status changes and other events.
The following table lists the pattern of sounds generated by the beeper, and the
events that cause them. By default, the beeper will sound for all the events listed in
the table, but alerts for some events may be turned off by your site supervisor.
Event Sounds when... Pattern
Inside Avoidance Zone The machine is inside an avoidance zone. Repeated:
150 msec on,
175 msec off,
300 msec on,
175 msec off
Table 2.3 — Beeper patterns
42 GCS900 Grade Control System for Excavators Operator's Manual
