Trimble GCS900 - 2.4.1 Power key; 2.4.2 System memory and the USB flash drive

2 Using the Control Box and Lightbars
Description Function
LCD screen Displays guidance information
Softkey labels See
Softkey labels, page 29
Softkeys See
Softkeys, page 27
Zoom-in key
+
Zoom in on the machine
Zoom-out key
-
Zoom out from the machine
Next key
N
View the next guidance screen or select the next field in a dialog
Menu key
M
View the
Setup Menu – Configuration
dialog
USB flash drive port See
2.4.2 System memory and the USB flash drive
Arrow keys
( )
[ ]
Pan a guidance view, select an item in a list, or enter data in a field
OK key
\
Save changes made in a dialog, and exit the dialog
Escape key
=
Exit from a dialog without saving changes, or exit from a menu
Power key
P
See
2.4.1 Power key
Beeper
See 2.8 System beeper
2.4.1 Power key
The P key turns the control box on and off.
To turn on the control box and the system, press P. After a brief pause, an
opening screen appears.
Note – If the system reports that there are upgrade files or other system files on the
control box, or that the operating system is out of date, contact your site supervisor
immediately.
To turn off the control box and the system, press and hold P for two to three
seconds until the control box shuts down. (This delay reduces the risk of you turning
off the power accidentally.) You can turn off the system from any screen or dialog.
2.4.2 System memory and the USB flash drive
Files and data are stored on the control box in an area known as system memory.
The files and data in system memory are used by the system and there is only
limited site supervisor access via the control box.
22 GCS900 Grade Control System for Excavators Operator's Manual
