Using theControl Box and Lightbars 2
l The guidance configuration of the system. Your selection of guidance method
affects the guidance information available on the display and the guidance
configuration options you get.
l The operator configuration of the system. The menus and screens selected for
you by your site supervisor affect the setup information you can view and
modify.
Note – This manual only covers the menu options that are available to
operators by default.
Any configuration and guidance options not covered in this manual are described in
the GCS900 Grade Control System Site Supervisor’s Manual.
2.5.1 Working with menus and dialogs
Before you can begin work, you must enter configuration and set-up information into
the system, and view the current system state, by using screens called menus and
dialogs. Menus let you select a dialog. Dialogs let you specify set-up and
configuration information, or view information about the state of system
components.
The plan view guidance screen appears when you initially start the machine. If you
navigate away from this screen before you enter configuration and set-up
information into the system, press = until you escape back to any guidance screen
view. Then press M to select a dialog and enter the required configuration and set-
up information.
Softkeys
Softkeys are the six physical keys immediately to the right of the screen. Softkey
labels are the graphical “keys” that appear down the side of the screen beside each
physical softkey; the softkey labels identify the function of the physical softkeys .
The following tables list the softkey labels that display on the guidance screens, and
briefly describe each softkey's meaning.
Generic 3D softkey icons
Icon Functionality
Direction:Unknown
– Direction of motion is unknown. Press to open the
Direction
dialog.
GCS900 Grade Control System for Excavators Operator's Manual 27
