Preparingto Work 3
3.3.3 Main screen views
The Main Screen Views dialog enables you to configure some views on the main
screen to suit the specifics of the current job and environment.
The following tables describe the functions that you can adjust in the Main Screen
Views dialog.
Note – Some of the items listed in the following tables may not apply to your system.
Item Options Description
Plan (no mapping) Yes / No Yes - A plan view with no mapping content is available.
Terrain Yes / No Yes - A plan view with terrain mapping is available.
Cut/Fill Yes / No Yes - A plan view with cut/fill mapping is available.
Pass count Yes / No Yes - A plan view with pass count is available.
Radio coverage Yes / No Yes - A plan view with radio coverage mapping is
available.
Profile Yes / No Yes - A profile view is available.
Cross section Yes / No Yes - A cross section view is available.
Split view Yes / No Yes - A profile and cross section split view is available.
Text view 1 Yes / No Yes - A text view is available.
Text view 2 Yes / No Yes - A second text view is available.
Level view Yes / No Yes - A level bubble view is available.
Table 3.1 — Main screen views - Active views
Item Options Description
Mapping Softkey
l None
l Mapping: On/Off
l Reset Maps
l Record Point
Configure the function of the main screen
view Mapping Softkey.
Press and Hold
l None
l Record Point
l Increment Layer
l When Record Point is selected, press
and hold Record Point or
Mapping/Recording to display the
Record Point dialog.
l When Increment Layer is selected,
press and hold Increment Layer to
display the Mapping/Recording
dialog.
Table 3.2 — Main screen views - Main Screen Softkeys
GCS900 Grade Control System for Excavators Operator's Manual 53
