Preparingto Work 3
Note – If you have a dual band SNRx10 radio, make sure that both radio
modules are assigned a radio network ID so that you can switch between radio
bands if necessary. For more information, see 3.5.4 Select radio band.
The changes take effect immediately. The network number is uploaded to the
machine radio, and the machine radio is programmed as a rover radio.
For 900 MHz and 2400 MHz radios, the network number is stored in the
control box. Whenever you start the system, the control box automatically sets
the same network number in the machine radio. For example, if a radio is
moved from one machine to another, the control box automatically sets the
same radio network that was configured for the previous radio.
The Radio Status field can provide the following messages:
This message ... Displays when the ...
Not Found
System cannot communicate with the radio.
Configuring
Radio is currently being configured.
Configuration failed
Radio configuration failed.
Connected
Radio connects to the system.
App <version num.>
required
Radio firmware must be upgraded to the specified version.
Loader <version num.>
required
Radio firmware must be upgraded to the specified version.
System Error
Firmware is not installed correctly.
This radio type cannot be
configured.
System connects to an unsupported radio.
UTS incompatible
System connects to a 900MHz radio for use with an SPSx30 UTS.
Note – The Manage Freq and Wireless Mode softkeys are only displayed when either
a 220 MHz or 450 MHZ radio is configured
To manage and add a frequency, press Manage Freq.
To configure the wireless mode, press Wireless Mode.
GCS900 Grade Control System for Excavators Operator's Manual 61
