Unipulse F701-C User Manual

9.EXTERNAL INPUT/OUTPUT SIGNALS (CONTROL CONNECTOR)
116
9-4-9. Accumulation command <Edge Input>
An immediate accumulation is executed at the ON edge (OFF → ON) of the external input.
The weight value (gross or net) set in the over/under comparison mode is accumulated.
9-4-10. Accumulation Clear <Edge Input>
Immediate clearing of accumulated data and statistical data is executed at the ON edge (OFF →
ON) of the external input.
OFF
ON
Pulse width 50msec or more
OFF
ON
Pulse width 50msec or more
