9.EXTERNAL INPUT/OUTPUT SIGNALS (CONTROL CONNECTOR)
123
9-5-11. Output selection
Each signal of the weight error, sequence error, complete, go, RUN, and accumulation error outputs
is selective by setting.
Weight error and sequence error
The weight error and sequence error are outputted from output selection 1 of B9 pin.
Complete and Go
The complete and go are outputted from output selection 2 of B10 pin.
RUN and accumulation error
The RUN and accumulation error are outputted from output selection 3 of B11 pin.
Operation
1) Select setting mode 5.
2) Set the Output selection 1, 2 and 3. (2-Output Selection)
→→→
F
CNG/ENT CNG/ENT
5
SP2
→→ →
CNG/ENT CNG/ENT
2
LOWER
Output selection 3 (B11 pin)
1 : Accumulation Error
0 : RUN
Output selection 1 (B9 pin)
2 : Weight error
or sequence error
1 : Sequence error
0 : Weight error
Output selection 2 (B10 pin)
1 : Complete output
0 : Go output
