Unipulse F701-C User Manual

10.INTERFACE
147
◇ One to multiple connection
10-5-3. Setting Values for RS-485
1. Set the RS-485 port of this equipment.
Operation
1) Select setting mode 4.
2) Set the RS-485 port. (4-RS-485 I/F)
2. The initial set for RS-485 port of connecting personal computer and
sequencer should be the same setting of F701-C.
A
B
RD
A
B
SD
ABAB
SD RD
ABAB
SD RD
ABAB
SD RD
ABAB
SD RD
Rt
Twisted-para-cable
F701-C F701-C F701-C F701-C
Rt
120ΩRt can be
installed or removed
according to the switch.
The switch is available on the option
sheet metal section at the back
of the main unit.
Rt
OFF
Rt
OFF
Rt
OFF
Rt
ON
CNG/ENT
→→→
F
CNG/ENT
4
SP1
Baud rate
5 : 38400bps
4 : 19200bps
3 : 9600bps
2 : 4800bps
1 : 2400bps
0 : 1200bps
Terminator
1 : CR+LF
0 : CR
Character length
1 : 8bit
0 : 7bit
Stop bit
1 : 2bit
0 : 1bit
Parity bit
2 : Even
1 : Odd
0 : None
→→ →
4
SP1
CNG/ENT CNG/ENT
