4.CALIBRATION
42
4-2. Span Calibration Procedure
Follow the steps below to perform Span Calibration.
Release calibration inhibit LOCK by the switch OFF on the rear
panel.
Release Setting Value LOCK which inhibits the calibration.
The displayed unit is set.
Register the position of decimal point.
Register the maximum capacity of the scale.
If the registered value exceeds by 9 scale divisions, display shows
over scale, “ ”.
Register the minimum unit (scale division) of the scale.
Register the value of load (balance weight) for load cell.
Calibrate the initial zero point.
Place the load (balance weight) on the load cell and register the
span value.
If it is necessary, re-calibrate initial zero point.
Disable changing setting value related to calibration.
Turn the calibration LOCK ON to prohibit the calibration for
avoiding false operation.
Release Calibration LOCK
Decimal Place
Min. Scale Division
Capacity
Balance Weight Value
Zero Calibration
Span Calibration
Zero Calibration
Calibration LOCK
LOCK Switch OFF
LOCK Switch ON
Unit
