9.EXTERNAL INPUT/OUTPUT SIGNALS (CONTROL CONNECTOR)
120
9-5-8. SP1, SP2, SP3
◆ In simple comparison mode
SP1 turns ON when W
eight value ≧ Final - SP1
SP2 turns ON when Weight value ≧ Final - SP2
SP3 turns ON when Weight value ≧ Final - CPS
* For the method of setting, refer to "6-4.Final / Set Point 2 / Set Point 1 / Compensation / Over /
Under" on P.86, "6-7.Upper/Lower Limit Comparison / Upper/Lower Limit Comparison Mode /
Near Zero Comparison / Final and Comparison / Over/Under Comparison Mode" on P.91.
◆ In sequence mode
In sequence mode, the weighing sequence is started at the ON edge of the start signal (OFF → ON),
Set Point 1, Set Point 2 and Set Point 3 turn ON.
SP1 turns OFF when W
eight value ≧ Final - SP1
SP2 turns OFF when W
eight value ≧ Final - SP2
SP3 turns OFF when Weight value ≧ Final - CPS
* For the method of setting, refer to "6-4.Final / Set Point 2 / Set Point 1 / Compensation / Over /
Under" on P.86, "6-7.Upper/Lower Limit Comparison / Upper/Lower Limit Comparison Mode /
Near Zero Comparison / Final and Comparison / Over/Under Comparison Mode" on P.91, "9-4-
11.Input Selection" on P.117.
Final, Set Point 1, Set Point 2, Compensation
in setting mode 0
Final and Over/Under comparison under Weighing Function 1
in setting mode 2
Final, Set Point 1, Set Point 2, Compensation
in setting mode 0
Final and Over/Under comparison under Weighing Function 1
in setting mode 2
To Next Page
