9.EXTERNAL INPUT/OUTPUT SIGNALS (CONTROL CONNECTOR)
118
9-5. External Output Signal
9-5-1. Near Zero
The output turns ON when Weight value ≦ Set value of Near Zero.
* For the method of setting, refer to "6-6.Near Zero / Upper Limit / Lower Limit" on P.90, "6-
7.Upper/Lower Limit Comparison / Upper/Lower Limit Comparison Mode / Near Zero
Comparison / Final and Comparison / Over/Under Comparison Mode" on P.91.
9-5-2. Lower Limit, Upper Limit
Select from comparison regularly or comparison at external judging ON in Upper/Lower limit
comparison mode.
Conditional expression
The lower limit output turns ON when Weigh
t value ＜ Lower Limit
The upper limit output turns ON when Weight value ＞ Upper Limit
* For the method of setting, refer to "6-6.Near Zero / Upper Limit / Lower Limit" on P.90, "6-
7.Upper/Lower Limit Comparison / Upper/Lower Limit Comparison Mode / Near Zero
Comparison / Final and Comparison / Over/Under Comparison Mode" on P.91.
9-5-3. Stable
This output turns ON when the weight value is stable.
* Refer to "5-6.Motion Detection (MD)" on P.58 for details.
9-5-4. Weight Error
When the display is LOAD, OFL or ZALM, the output turns ON.
* For the method of setting, refer to "6-11.Weight Error / Sequence Error" on P.101.
* For the error display, refer to "11.OVER SCALE & ERROR" on P.157.
Near Zero in setting mode 0
Near zero comparison under Weighing Function 1 in setting mode 2
Upper/Lower limit comparison mode under Weighing Function 2
in setting mode 2
Upper/Lower Limit
in setting mode 0
Upper/Lower limit comparison under Weighing Function 1
in setting mode 2
