17.SPECIFICATIONS
174
CC-Link interface [CCL]
Links directly to PLC.
CC-Link I/F operates as the remote device stations corresponding to CC-Link Ver.1.10.
Refer to F701-C CC-Link I/F specifications for details.
17-6. General Performance
Power supply voltage AC100 ~ 240V (+10, -15) [free power source 50/60Hz]
Power consumption Approx. 15VA
Rush current 20A, 5mSec : 100V AC mean load state
(ordinary temperature, at cold-start time)
40A, 5mSec : 200V AC mean load state
(ordinary temperature, at cold-start time)
Operating conditions Temperature : Operation -10 ~ +40
Storage -20 ~ +85
Humidity : 85%RH or less (non-condensing)
Dimension 144 (W) × 72(H) × 160(D) [mm]
* Projections excluded
Panel cutout size
Weight Approx. 1.0 [kg]
138W ×68H [mm]
2
0
1
0
