Unipulse F701-C User Manual

10.INTERFACE
128
10-2-5. Transmission Format
- Transmission format 1
- Transmission format 2
- Transmission format 3
012345678910111213141516171819
GS ,*1 *2 *3 *4,, ,, CRLF±
HEADER Gross weight, 5-digit + decimal point
Sign
＋ or －
012345678910111213141516171819
NT ,*1 *2 *3 *4,, ,, CRLF±
HEADER Net weight, 5-digit + decimal point
Sign
＋ or －
012345678910111213141516171819202122
W T *1 *2 *3 *4 ±
HEADER Net weight, 5-digit
Sign (gross weight)
＋ or －
Gross weight, 5-digit
*5
SOH STX ETX BCC
Sign (net weight)
＋ or －
±
For BCC calculation
Each ASCII code of SOH,STX and ETX
SOH: 01 STX: 02 ETX: 03
BCC : Block check character
It is calculated as the XOR of the transmitted character (Hexadecimal).
*1 O : Overload (LOAD,OFL)
S: Stable
M: Unstable
H: Hold
Priority H > O > (S or M)
*4 N : Near zero OFF
Z : Near zero ON
*2 A : Zero tracking OFF
T : Zero tracking ON
Z: Zero error
Priority Z > (T or A)
*5 Decimal place
3 : 0.000
2 : 0.00
1 : 0.0
0: 0
*3 H : Upper limit ON
L : Lower limit ON
G : Upper limit and Lower limit OFF
N : Upper limit and Lower limit ON
F : Comparison OFF
Priority N > (H or L)
