2.CONNECT
ION
8
2. CONNECTION
2-1. Load cell Connection
The voltage application
of F701-C is 10V
, and th
e maximu
m current is 120mA, to which up to four
350
Ω
load cells can be connected in parallel.
Load cell terminal block pin assignme
nts
Pin No.
Signal (6-wire)
Signal (4-wire)
1+
S
I
G
+
S
I
G
2-
S
I
G
-
S
I
G
3+
E
X
C
+
E
X
C
(Connect 3 to 4)
4+
S
5
-EXC
-EXC
(Connect 5 to 6)
6-
S
7
SHIELD
SHIELD
Load cell ter
minal block
18
20
