1.APPEARANCE DESCRIPTION
7
⑤ RS-232C connector
RS-232C connector for receiving and transmitting weight data and status information.
The applicable connector is JAE DE-09SN or its equivalent.
⑥ SI/F terminal block
2-wire serial interface is to connect unipulse peripheral equipment such as printer, remote display
or data converter.
⑦ LOCK switch
LOCK switch for avoiding changes of setting value, it prohibits to change setting value while the
switch is ON.
⑧ Load cell input terminal block
This is a terminal block to connect load cell(s).
The applicable terminal block is Osada-manufactured ETB42-07P.
⑨ Option space
One of the following options can be mounted.
- BCD parallel data output interface (BCO)
- D/A converter (DAC)
- RS-485 communication interface (485)
- CC-Link interface (CCL)
