Unipulse F701-C User Manual

9.EXTERNAL INPUT/OUTPUT SIGNALS (CONTROL CONNECTOR)
117
9-4-11. Input Selection
On each pin of input selection 1 (B2) to 4 (B5) of the external input/output signals, the input signal
can be selected by setting.
Settable items are accumulation clear, accumulation command, stop, start, feed/discharge, judge,
and hold (common to input selection 1 to 4).
However, except the hold signal, the same signal cannot be selected on two or more pins. If the
same signal is selected on two or more pins, forced setting of “HOLD” will result.
When “HOLD” is selected on two or more pins, the weight value is held if at least one signal is ON.
Operation
1) Select setting mode 5.
2) Set the Input selection items. (1-Input Selection)
→→→
F
CNG/ENT CNG/ENT
5
SP2
→→ →
CNG/ENT CNG/ENT
1
UPPER
Input selection 1 (B2 pin)
Input selection 3 (B4 pin)
6 : Accumulation Clear
5 : Accumulation Command
4 : Stop
3 : Start
2 : Feed/Discharge
1 : Judge
0 : HOLD
Input selection 2 (B3 pin)
Input selection 4 (B5 pin)
6 : Accumulation Clear
5 : Accumulation Command
4 : Stop
3 : Start
2 : Feed/Discharge
1 : Judge
0 : HOLD
6 : Accumulation Clear
5 : Accumulation Command
4 : Stop
3 : Start
2 : Feed/Discharge
1 : Judge
0 : HOLD
6 : Accumulation Clear
5 : Accumulation Command
4 : Stop
3 : Start
2 : Feed/Discharge
1 : Judge
0 : HOLD
