2.CONNECTION
14
2-5. Connection of the Control Connector
Connect to the control connector (rear panel “CONTROL”).
The applicable connector is the following (accessory) manufactured by Fujitsu Component or an
equivalent:
Connector : FCN-361J024-AU
Cover : FCN-360C024-B
2-5-1. Control Connector-Pin Assignment
For details, please refer to "9.EXTERNAL INPUT/OUTPUT SIGNALS (CONTROL
CONNECTOR)" on P.111.
* ＊ : The COM (common) terminals are connected inside.
* *1 : Selectable by setting.
(For details, please refer to "9-4-11.Input Selection" on P.117)
* *2 : Selectable by setting. (For details, please refer to "6-11.Weight Error / Sequence Error" on
P.101, "6-8.Complete Signal Output Mode / Complete Output Time / Judging Time /
Comparison Inhibit Time / Output Selection 2" on P.93, "9-5-7.Accumulation Error" on
P.11 9)
* SP1 turns ON when Weight value ≧ Final - SP1
SP2 turns ON when Weight value ≧ Final - SP2
SP3 turns ON when Weight value ≧ Final - CPS
A1
＊
COM B1
＊
COM
A2 In G/N B2 In Input Selection 1 *1
A3 In D/Z ON B3 In Input Selection 2 *1
A4 In Tare Subtraction ON B4 In Input Selection 3 *1
A5 In Tare Subtraction OFF B5 In Input Selection 4 *1
A6 Out Near Zero B6 Out Lower Limit
A7 Out SP1 B7 Out Upper Limit
A8 Out SP2 B8 Out Stable
A9 Out SP3 B9 Out Output Selection 1 *2
A10 Out Under B10 Out Output Selection 2 *2
A11 Out Over B11 Out Output Selection 3 *2
A12
＊
COM B12
＊
COM
To Next Page
