6.DISCHARGING CONTROL MODE
89
6-5. Negative Compensation
The selection whether the negative value of input range of compensation is including or not.
Select from Effect/ Inhibit.
- Inhibit ....................Not including the negative value of the input range of compensation.
(Input range is 0 ~ 9999.)
- Effect .....................Including the negative value of the input range of compensation.
(Input range is -9999 ~ 9999.)
Operation
1) Select setting mode 2.
2) Input the Negative Compensation. (3-Weighing Function 3)
→→→
F
CNG/ENT CNG/ENT
2
LOWER
1 : Effect
0 : Inhibit
→→→
CNG/ENT CNG/ENT
3
NEAR Z .
Negative Compensation
