10.INTERFACE
140
10-3-9. BCD Data Update Rate Selection
1) Select setting mode 4.
2) Set the Data update rate. (7-External Function Selection)
10-3-10. Data Hold Input
When this input terminal is short-circuited with the COM terminal, the BCD data is held.
(No strobe pulses are output.)
10-3-11. Logic Switching Input
The output signal logic is switched.
Open : negative
Short : positive
10-3-12. Output Selection Input
Select weight values to be output as BCD data.
Data update rate
7 : 1 times/sec. STROBE range Approx. 500msec
6 : 2 times/sec. STROBE range Approx. 250msec
5 : 5 times/sec. STROBE range Approx. 100msec
4 : 10 times/sec. STROBE range Approx. 50msec
3 : 20 times/sec. STROBE range Approx. 25msec
2 : 50 times/sec. STROBE range Approx. 10msec
1 : 100 times/sec. STROBE range Approx. 5msec
0 : 200 times/sec. STROBE range Approx. 2.5msec
→
→
→
7
OVER
CNG/ENT CNG/ENT
Selection 1 Selection 2 Weight value
Open Open Weight value displayed by the main unit
Open Short Net weight
Short Short Gross weight
Short Open Tare weight
To Next Page
