17.SPECIFICATIONS
171
17-2. Display Section
Display
Main display : Numerical display (7-digit) by fluorescent character display tube;
10.4mm in character height
Subdisplay :
Numerical display (18-digit) by fluorescent character display tube;
4.0mm in character height
Indicated value 5-digit, sign: negative display at the highest digit
Unit Label attached (t, kg, g, N, lb)
Capacity Setting allowable in the range of 0 ~ 99999.
Min. scale division Setting allowable in the range of 1 ~ 100.
Decimal point Select from 0, 0.0, 0.00 or 0.000
Over display A/D converter input over LOAD
Net Over OFL1
Capacity + 9 scale division OFL2
Gross Over OFL3
Center zero A true zero point or the center of each value is displayed.
Display frequency Select from 3, 6, 13 or 25 times/sec.
(The system speed is 200 times/sec.)
Status display SP1, SP2, SP3, NEAR Z, HOLD, ZALM, STAB, TARE, NET,
ZERO,
17-3. Setting Section
Setting method Setting by keyboard operation
(embossed membrane switches with key click sound)
External setting also allowable through the RS-232C.
Memory of set values
Initial values : NOV RAM (nonvolatile RAM)
Other values : Lithium-battery-backed-up C-MOS RAM
(The memory period is 7 years or more.)
(With the lithium battery voltage monitoring function.)
Protection of set values Setting operation is inhibited so that initial setting values and
calibration will not be changed by wrong operation.
Setting item - Upper Limit / Lower Limit / Near Zero / Set Point 1 / Set Point 2 /
Compensation / Over / Under / Final
- Comparison Inhibit Time / Judging Time / Complete Output Time /
Adjust Feeding Time / Auto Zero Times / Judging Times /
Auto Free Fall Compensation Regulation / Analog Filter / Tare Weight
