11.OVER SCALE & ERROR
157
11. OVER SCALE & ERROR
11-1. Over Scale
The weight error output turns ON.
* Net weight = Gross weight - Tare weight
11-2. Sequence Error
The sequence error output turns ON.
* SP1 = Final - Set point 1
The input of A/D converter overflowed
Net weight ＞ Net Over set value
Gross weight ＞ Capacity + 9 scale division
Gross weight ＞ Gross Over set value
Error item Alarm message
When start signal turns on, the stop signal turns ON.
During weigh cycle, the stop signal turns ON.
Zero Alarm turns on according to set times.
When the start of weighing, Near Zero output signal turns
OFF.
("At start, Near Zero confirmation on" is selected for
sequence control.)
When the start of weighing, the value ≧ SP1*.
("At start, weight value confirmation on" is selected for
sequence control.)
Or, (Final - Compensation) ＜ 0 at the start of weighing.
