17.SPECIFICATIONS
172
- Weighing Function 1 / Weighing Function 2 / Weighing Function 3 /
Sequence Mode / Function Key Invalid / Digital Filter /
Motion Detection / Zero Tracking Period / Zero Tracking Range
- Balance Weight Value / Capacity / Min. Scale Division /
Net Over / Gross Over / DZ Regulation Value / Function Selection /
Gravitation Acceleration (area number input) /
Gravitation Acceleration (acceleration input)
- D/A Output Mode / D/A Zero Output Weight / D/A Full Scale /
RS-485 I/F / ID Number / RS-232C I/F / External Function Selection /
Setting Value LOCK / Restriction on the Tare Subtraction Function
- Optional Board
- Input Selection / Output Selection /
CC-Link I/F Occupied station & Transmission speed /
CC-Link Station No.
- Span Calibration / Equivalent Calibration / Pass Word / Zero Calibration
17-4. External Input/Output
Input signals G・N / Digital Zero / Tare ON / Tare OFF / Hold / Judge / Feed・Discharge /
(8 points) Start / Stop / Accumulation Command / Accumulation Clear
ON when short-circuited with the COM terminal by contact
(relay, switch, etc.) or non-contact (transistor, open collector output, etc.)
Output signals Near Zero / SP1 / SP2 / SP3 / Under / Over / Upper Limit / Lower Limit /
(12 points) Stab / Weight Error・Error / Go・Complete / RUN・Accumulation Error
Transistor open collector output
(Emitter = COM terminal)
Output LO with transistor ON.
17-5. Interface
< Standard equipment >
Two-wire serial interface [SI/F]
Serial interface to connect a UNIPULSE-manufactured printer, external display, etc.
Transmitting method : Asynchronous
Transmitting speed : 600bps
RS-232C communication interface [232]
Writing, changing, reading, etc., of weight data and various types of status, and additionally
various setting values are carried out by commands from the host computer.
Signal level : Based on RS-232C
Transmission distance : Approx. 15ｍ
Transmitting method : Asynchronous
Transmitting speed : 1200, 2400, 4800, 9600, 19200 or 38400bps selectable
