3-2. Setting Mode
Setting mode 0 Setting mode 1 Setting mode 2 Setting mode 3
Upper Limit
/ P.24
Comparison Inhibit Time
/ P.26
Weighing Function 1
/ P.28
Balance Weight Value
/ P.31
Lower Limit
/ P.24
Judging Time
/ P.26
Weighing Function 2
/ P.28
Capacity
/ P.31
Near Zero
/ P.24
Complete Output Time
/ P.26
Weighing Function 3
/ P.29
Min. Scale Division
/ P.31
Set Point 1
/ P.24
Adjust Feeding Time
/ P.26
Sequence Mode
/ P.29
Net Over
/ P.31
Set Point 2
/ P.24
Auto Zero Times
/ P.26
Function Key Invalid
/ P.30
Gross Over
/ P.31
Compensation
/ P.24
Judging Times
/ P.26
Digital Filter
/ P.30
DZ Regulation Value
/ P.31
Over
/ P.25
Auto Free Fall
Compensation Regulation
/ P.27
Motion Detection
/ P.30
Function Selection
/ P.32
Under
/ P.25
Analog Filter
/ P.27
Zero Tracking Period
/ P.30
Gravitational Acceleration
(area number)
/ P.32
Final
/ P.25
Tare Weight
/ P.27
Zero Tracking Range
/ P.30
Gravitational Acceleration
(acceleration)
/ P.32
* When each setting mode is selected, the 1 ~ 9 keys function as setting item selection keys.
Setting mode 4 Setting mode 5 Setting mode 8 Setting mode 9
D/A Output Mode
/ P.33
Input Selection
/ P.36
Average Weight
/ P.38
Span Calibration
/ P.53
D/A Zero Output Weight
/ P.33
Output Selection
/ P.36
Max. Value
/ P.38
Equivalent Calibration
/ P.54
D/A Full Scale
/ P.33
CC-Link I/F
Number of occupied station &
Transmission speed
(Refer to separate-volume spec.
)
Min. Value
/ P.38
RS-485 I/F
/ P.33
CC-Link I/F
Station No.
(Refer to separate-volume spec.
)
General Standard Deviation
/ P.38
ID Number
/ P.34
Sample Standard Deviation
/ P.38
RS-232C I/F
/ P.34
Accumulation Count (n)
/ P.38
External Function Selection
/ P.35
Latest Accumulation Data
/ P.38
Setting Value LOCK
/ P.35
Max. - Min. (R)
/ P.39
Restriction on the Tare
Subtraction Function
/ P.35
Option Board
/ P.39
Pass Word
/ P.109
Zero Calibration
/ P.51
