Installation TITANUS MICRO·SENS
®
5 – 4 Data: 01/09 MS_A_05-en-e
Installation equipment
TITANUS
®
Cylinder or flat head screws
– Thread diameter: max. 4 mm
– Head diameter: max. 8 mm
Hole distances The dimensions (all dimensions in mm) of the holes for fixing the
TITANUS MICRO·SENS
®
are shown in the following Figures.
200
140
122
130
Fig. 5.3: Hole distances TITANUS
®
MICRO·SENS
®
base unit
