Western Scale M2000 - DF1500 String

HIGH SPEED DIGITAL WEIGHT INDICATORS
102
DF1500 STRING
<STX><POL><WWWWWWW><SP><Units><SP><Mode><SP><Status><CR><LF>
POSITION CHARACTER CHARACTER VALUES
1 STX
Start of Text Character (ASCII 02)
2 Polarity
“-“ for Negative , Space for Positive
3 W
4 W
5 W
6 W
7 W
8 W
9 W
Weight String (Padded with spaces, includes
decimal point)
Least Significant Digit
10 Space
ASCII 32
11 Units
12 Units
“KG” = Kilograms
“LB” = Pounds
13 Space
ASCII 32
14 Mode
15 Mode
“GR” = Gross weight
“NT” = Net weight
16 Space
ASCII 32
17 Status Space=Valid, “O”=Over, “M”=Motion, “-“=Negative
18 CR Carriage Return (ASCII 13)
19 LF Line Feed (ASCII 10)
