HIGH SPEED DIGITAL WEIGHT INDICATORS
44
98P
0
1P
29P
C 4998
SCALE CHANNEL & TOTAL MODE PARAMETERS
ENABLE SCALE CHANNEL - PARAMETER 98
Description: Enables Scale Channels 2 or 3. By default, channels 2 and 3 are
turned off.
Channel 1 is always enabled.
To enable a channel, enter Calibration Mode for that channel
.
Press 1 followed by the [PRINT/SECLECT] key.
To disable the channel, enter 0 followed by the [PRINT/SECLECT]
key.
PARAMETER VALUE SCALE CHANNEL
0 (default)
Disabled
1
Enabled
EXAMPLE: ENABLE SCALE CHANNEL 2.
1. Enter Calibration Mode for Scale Channel 2.
2. Select Parameter 98. The current value (0) will be shown
3. Press 1 followed by the [PRINT/SELECT] key.
4. Set-up and calibrate scale connected to Channel 2.
