TECHNICAL MANUAL
PARAMETER 61 - CURRENT LOOP OFFSET ADJUSTMENT (ZERO)
Description: Sets the 4 mA base current value (the value of the output
board when the scale is at zero). The technician selects a
Current Output Value (from the M2000) that will correspond
to a 4 mA output by the 4-20 mA board.
Range: The Current Output Value is a linear representation of the
current and can be adjusted from 0 to 65530.
To make the process of arriving at the target current as easy
as possible, preset current output values are assigned to
HOT KEYS. The key assignments are shown below:
PARAMETER VALUE CURRENT OUTPUT VALUE
1 (default)
Preset Output to 0
2
Preset Output to 10000
3
Preset Output to 20000
4
Preset Output to 30000
5
Preset Output to 40000
6
Preset Output to 50000
7
Preset Output to 60000
8
Current value
FINE TUNING: The Current Output Value can be micro-adjusted:
Increase Current Output Value
Decrease Current Output Value
• When the Current Output Value results in a 4 mA output from the 4-20 mA
board, press [TARE] to lock in the current output value.
• To abort without saving changes, press the [CLEAR] key.
.
