TECHNICAL MANUAL
ENTERING SETPOINT VALUES
Parameters 51-56 are used to enter Setpoint values. Each of the 6 Setpoints
has its own weight compare registers. The values entered into these registers
will control the Setpoint relays. Setpoint values may be changed in Normal
Weighing Mode.
PARAMETER 51: Enter weight for Setpoint 1, followed by [PRINT/SELECT].
PARAMETER 52: Enter weight for Setpoint 2, followed by [PRINT/SELECT].
PARAMETER 53: Enter weight for Setpoint 3, followed by [PRINT/SELECT].
PARAMETER 54: Enter weight for Setpoint 4, followed by [PRINT/SELECT].
PARAMETER 55: Enter weight for Setpoint 5, followed by [PRINT/SELECT].
PARAMETER 56: Enter weight for Setpoint 6, followed by [PRINT/SELECT].
SETPOINT HYSTERESIS ADJUSTMENTS - PARAMETER 58
Description: Hysteresis adjustments are used when vibrations in the scale
cause the Setpoints to falsely trigger. Increasing the Hysteresis
value increases the weight settling period for accepting a Setpoint
value.
Accepted Values: 6 digits are required (each digit represents each Setpoint as
in Parameter 57). Each digit can have a value of 0 to 9.
PARAMETER VALUE SETPOINT FUNCTION
0 (default)
Output action on the first occurrence of a weight
evaluation of the Setpoint.
1 Energize output when weight < Setpoint value.
2 Energize output when weight >= Setpoint value.
9
The Setpoint will only change after an evaluation has
occurred for 9 consecutive weight samples in a row.
The Parameter Value is internally multiplied by 10. A Hysteresis
factor of 3 will translate to 30 valid weight comparisons to the
Setpoint before an output action will take place.
NOTE THE UNITS OF MEASUREMENT! TO ENTER A SETPOINT
VALUE IN KILOGRAMS, MAKE SURE THE M2000 IS
CURRENTLY WEIGHING IN KILOGRAMS.
